The LM96530SQX/NOPB is a high-performance, quad-channel ultrasound transmit pulser developed by Texas Instruments. This advanced integrated circuit (IC) is designed to meet the stringent requirements of modern medical ultrasound imaging systems, providing precise control and high-quality signal transmission for clear and accurate diagnostic images.

Key Features

• Quad-Channel: This device features four independent channels, enabling simultaneous pulsing for multiple transducer elements, which is essential for phased array and other multi-element transducers.
• High Voltage: The pulser can generate peak voltages up to +/- 50V, ensuring strong and clear signals for deep tissue imaging.
• Variable Pulse Width: The LM96530SQX/NOPB allows for adjustable pulse widths, giving users the flexibility to optimize for different imaging scenarios.
• Low Power Consumption: Designed for efficiency, the IC minimizes power usage, which is critical for portable and battery-powered ultrasound systems.
• Integrated Active Damping: The device includes built-in active damping to reduce ringing and improve the quality of the received echo signal.
• Thermal Protection: The built-in over-temperature protection ensures reliability and safety during operation.

Applications

The LM96530SQX/NOPB is primarily used in medical ultrasound imaging systems, including both cart-based and portable devices. Its versatility and high performance also make it suitable for industrial non-destructive testing (NDT) applications where precision imaging is required.

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the LM96530SQX/NOPB is no exception. It is available in a thermally-enhanced 32-lead LLP package that ensures reliable operation even under high power or high ambient temperature conditions. The device is also lead-free and RoHS compliant, adhering to environmental standards.

Ordering Information

The part number LM96530SQX/NOPB indicates that the device is provided in a tape and reel packaging suitable for automated assembly processes, and the 'NOPB' suffix denotes that the product is lead-free. For detailed ordering and shipping information, customers can consult the Texas Instruments website or contact their sales representatives.
