966658-1 Real Image
Same model may have multiple batches, images only for reference.

966658-1

Part No 966658-1
Manufacturer TE Connectivity
Catalog Circular Connectors - Housings
Description CONN HEADER VERT 32POS 2.54MM / Connector Header Through Hole 32 position 0.100" (2.54mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series AMPMODU Mod II
Package Tray
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Number of Positions 32
Number of Rows 2
Row Spacing - Mating 0.100" (2.54mm)
Number of Positions Loaded All
Style Board to Board or Cable
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Latch Holder
Contact Length - Mating 0.268" (6.80mm)
Contact Length - Post 0.098" (2.50mm)
Overall Contact Length 0.520" (13.21mm)
Insulation Height 0.795" (20.20mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 78.7µin (2.00µm)
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polybutylene Terephthalate (PBT), Glass Filled
Features Board Lock
Temperature Range - Operating -40°C ~ 110°C
Insulation Color Green
Voltage Rating 12V
Applications Automotive
Base Product Number 966658
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Names -966658-1-CSI,-966658-1-LSI,-966658-1-SI
Standard Package 288
Win Source Part Number 1136396-966658-1
Ultra Librarian 3D Model Ultra Librarian 966658-1 CAD Model

Description

The AMPMODU Mod II series header connector is a male pin connector from TE Connectivity AMP Connectors.

  • Series: AMPMODU Mod II
  • Positions: 32
  • Loaded Positions: All
  • Rows: 2
  • Termination: Soldering
  • Fastening Type: Latch Holder
  • Package: Tray
  • Contact Material: Brass
  • Contact Finish: Tin
  • Insulation Material: Polybutylene Terephthalate (PBT), Glass Filled
  • Insulation Color: Green
  • Contact Length (Mating): 0.268 inches (6.80mm)
  • Contact Length (Overall): 0.520 inches (13.21mm)
  • Insulation Height: 0.795 inches (20.20mm)
  • Contact Shape: Square
  • Temperature Range: -40 degrees Celsius to 110 degrees Celsius
  • Application: Board to Board or Cable Connections, Automotive
