770170-2 Real Image
Same model may have multiple batches, images only for reference.

770170-2

Part No 770170-2
Manufacturer TE Connectivity
Catalog Barrel - Power Connectors
Description CONN HEADER VERT 3POS 4.14MM / Connector Header Through Hole 3 position 0.163" (4.14mm)
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr TE Connectivity AMP Connectors
Series Mini-Universal MATE-N-LOK
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.163" (4.14mm)
Number of Positions 3
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole
Termination Solder
Fastening Type Locking Ramp
Contact Length - Post 0.175" (4.45mm)
Insulation Height 0.531" (13.50mm)
Contact Shape Circular
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 30.0µin (0.76µm)
Contact Finish - Post Tin-Lead
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Board Lock
Temperature Range - Operating -20°C ~ 105°C
Material Flammability Rating UL94 V-0
Insulation Color White
Current Rating (Amps) Varies by Wire Gauge
Voltage Rating 600VAC
Contact Finish Thickness - Post 150.0µin (3.81µm)
Applications General Purpose
Base Product Number 770170
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-770170-2,A25595,770170-2-ND
Standard Package 200
Win Source Part Number 991612-770170-2
Ultra Librarian 3D Model Ultra Librarian 770170-2 CAD Model

Description

TE Connectivity AMP Connectors brings you the Mini-Universal MATE-N-LOK series header connector with male pins that is designed for board to cable/wire style connectivity.

  • Positions: 3
  • Row: Single
  • Pitch-Mating: 0.163 inches (4.14 mm)
  • Insulation Material: Polyamide (PA), Nylon
  • Flammability Rating: UL94 V-0
  • Contact Material: Brass
  • Contact Finish (Mating): Gold
  • Contact Finish (Post): Tin-Lead
  • Voltage Rating: 600VAC
  • Temperature Range: -20°C to 105°C
  • Shrouded: 4 Walls
  • Mounting: Through-Hole
  • Fastening Type: Locking Ramp
  • Packaging: Bulk
  • Standard Package: 200 connectors per package
