DRL10-24-1 Real Image
Same model may have multiple batches, images only for reference.

DRL10-24-1

Part No DRL10-24-1
Manufacturer TDK-Lambda Americas Inc.
Catalog Custom Parts (B - D)
Description AC/DC CONVERTER 24V 10W /
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - External/Internal (Off-Board)>Industrial, DIN Rail Power Supplies
Mfr TDK-Lambda Americas Inc
Series DRL (10-100W)
Package Bulk
Input Type AC or DC
Number of Outputs 1
AC Voltage - Input 85 ~ 264 VAC
DC Voltage - Input (Min) 120V
DC Voltage - Input (Max) 373V
Voltage - Output 1 24V
Current - Output (Max) 420mA
Power (Watts) 10W
Voltage - Isolation 3 kV
Applications Hazardous Locations, ITE (Commercial)
Efficiency 87%
Temperature Range - Operating -20°C ~ 71°C (With Derating)
Features Universal Input
Dimension 2.19" L x 0.71" W x 3.58" H (55.6mm x 18.0mm x 91.0mm)
Approval Agency CE
Base Product Number DRL10
MSL Level Not Applicable
ECCN EAR99
HTSUS 8504.40.9510
Other Names 285-2644
Standard Package 1
Win Source Part Number 1113290-DRL10-24-1
Ultra Librarian 3D Model Ultra Librarian DRL10-24-1 CAD Model

Description

The DRL10-24-1 is a DIN Rail Power Supply by TDK-Lambda Americas Inc.

  • Manufacturer: TDK-Lambda Americas Inc.
  • Type: DIN Rail Power Supply
  • Power: 10W
  • Input: Universal
  • Application: Hazardous Locations and ITE (Commercial)
  • Voltage Isolation: 3 kV
  • Efficiency: 87%
  • Output: Single Output
  • Maximum Current: 420mA
  • Voltage Output: 24V
  • Temperature Range: -20°C ~ 71°C (With Derating)
  • Dimensions: 2.19" L x 0.71" W x 3.58" H (55.6mm x 18.0mm x 91.0mm)
  • Approvals: CE
  • AC Input Voltage: 85 ~ 264 VAC
  • DC Input Voltage: 120V to 373V
