STPS1H100AY - High Voltage Power Schottky Rectifier

The STPS1H100AY is a robust, high voltage power Schottky rectifier designed by STMicroelectronics, a leader in semiconductor solutions. This device is engineered to combine low voltage-drop characteristics with high-frequency operation, making it an ideal choice for a variety of switching power supplies and high-frequency DC to DC converters.

Key Features

• High Junction Temperature: Capable of operating at a junction temperature of up to 175°C, the STPS1H100AY ensures reliability and stability even under high temperature conditions.
• Low Forward Voltage Drop: The device offers a low forward voltage drop (VF), which enhances power efficiency by minimizing power loss during conduction.
• High Surge Current Capability: Designed to withstand high surge currents, this rectifier ensures durability and robust performance in applications subject to surge or peak currents.
• High Avalanche Capability: The device features high avalanche ruggedness, providing additional protection against unforeseen voltage spikes.

Applications

The STPS1H100AY is suitable for a diverse range of applications, including:

• Switching power supplies
• DC to DC converters
• Free-wheeling diodes
• Reverse battery protection
• Power management devices

Package Details

This power Schottky rectifier is available in a TO-220AC package, which is known for its ease of installation and excellent thermal performance. The package is designed to be used in environments where efficient heat dissipation is crucial.

Quality and Reliability

STMicroelectronics is committed to delivering high-quality products. The STPS1H100AY rectifier is no exception, as it is manufactured with the highest standards to ensure that it meets the rigorous demands of industrial and commercial applications. Customers can trust in the reliability and performance of this high voltage power Schottky rectifier for their critical power management needs.
