The STPS16170CB-TR is a cutting-edge Schottky rectifier designed by STMicroelectronics, a global leader in semiconductor solutions. This power Schottky rectifier stands out with its high current density and low forward voltage drop, making it an ideal choice for high-efficiency power supply applications.
Key Features
- High Junction Temperature Capability: This rectifier is capable of operating at high temperatures, with a maximum junction temperature of 175°C, ensuring reliability and stability in challenging conditions.
- Low Forward Voltage Drop: The device features a very low forward voltage drop, which reduces power losses and improves efficiency, particularly important in applications where energy conservation is critical.
- High Surge Current Capability: With its robust construction, the STPS16170CB-TR can handle high surge currents, providing excellent robustness against transient conditions.
- Dual Center Tap Configuration: The rectifier comes in a dual center tap configuration, housed in a TO-220AB package, which simplifies the design of parallel rectifier assemblies.
Applications
The STPS16170CB-TR is versatile and can be used in a variety of applications, including:
- Switching power supplies
- Converters
- Free-wheeling diodes
- Reverse battery protection
- Automotive applications
Product Specifications
Parameter
Value
Average Forward Current (IF(AV))
16 A
Repetitive Peak Reverse Voltage (VRRM)
170 V
Forward Voltage Drop (VF) at IF
0.69 V at 16 A
Operating Junction Temperature (TJ)
-40°C to +175°C
This product is part of STMicroelectronics' extensive range of Schottky rectifiers, known for their reliability, efficiency, and performance. The STPS16170CB-TR is a testament to the company's commitment to providing innovative and sustainable solutions to the electronics industry.
