The STM32F765VGT6 is a high-performance, advanced line microcontroller from STMicroelectronics, which is part of their STM32F7 series. This microcontroller is built on the ARM Cortex-M7 processor, the highest-performing member of the energy-efficient Cortex-M processor family, and it operates at a frequency of up to 216 MHz.

Key Features

• CPU: ARM Cortex-M7 running at up to 216MHz
• Flash Memory: 1 Mbyte of Flash memory
• RAM: 324 Kbytes of RAM, including 64 Kbytes of Data TCM RAM for critical real-time data + 16 Kbytes of instruction TCM RAM + 4 Kbytes of backup RAM
• Supply Voltage: 1.7 V to 3.6 V application supply and I/Os
• I/O Pins: 100+ GPIOs with a flexible set of peripherals
• Communication Interfaces: 4 x I2C, 4 x SPI, 6 x USART, 2 x UART, 2 x SAI, 3 x I2S, 1 x FDCAN, 1 x SDMMC, 2 x CAN
• Advanced Peripherals: Dual-mode Quad-SPI, LCD-TFT controller, Chrom-ART Accelerator™, hardware JPEG codec, SPDIFRX interface
• Analog: 3 x 12-bit ADC, 2 x 12-bit DAC
• Timers: Advanced-control timer, up to 14 general-purpose timers, low-power timer, 2 x watchdogs, SysTick timer
• Security: Hardware acceleration for AES 128, 192, 256, HASH (MD5, SHA-1, SHA-2), and HMAC
• Debugging: Serial wire debug (SWD), JTAG, Cortex-M7 Embedded Trace Macrocell™

The STM32F765VGT6 is designed for a wide range of applications, including motor drive and application control, medical equipment, industrial applications, PLCs, inverters, printers, scanners, alarm systems, video intercoms, and HVACs. Its rich set of peripherals, advanced security features, and high-speed communication interfaces make it ideal for complex and sophisticated applications that require high processing power and real-time performance.

Developers can take advantage of the STM32 comprehensive software HAL library, as well as various software examples available in the STM32Cube package. With its extensive ecosystem, including software tools, firmware libraries, and hardware development kits, the STM32F765VGT6 provides a scalable, flexible, and easy-to-use platform for building high-performance embedded systems.
