STM32F103RCT6TR Microcontroller

The STM32F103RCT6TR is a high-performance ARM Cortex-M3 32-bit RISC core operating at a frequency of up to 72 MHz. This microcontroller is part of the STM32F103xx medium-density performance line family, produced by STMicroelectronics, which is renowned for its balance between performance, power consumption, and cost.

Key Features

• CPU: ARM 32-bit Cortex-M3 CPU Core with a maximum operating frequency of 72 MHz, featuring high-speed embedded memories (Flash memory up to 256 Kbytes and SRAM up to 48 Kbytes), and an extensive range of enhanced I/Os and peripherals.
• Performance: The device delivers an impressive 1.25 DMIPS/MHz (Dhrystone 2.1) performance with a memory protection unit which enhances application security.
• Connectivity: Offers various communication interfaces including two I2C, three USARTs, two SPIs, and CAN interfaces, which allow for flexible connection to different systems.
• Analog: Equipped with 12-bit ADCs, DAC channels, and general-purpose and advanced-control timers, it provides a robust set of analog and timing features.
• Debugging: Features a serial wire debug (SWD) and JTAG interfaces for full-speed system development.
• Power Efficiency: Supports multiple power modes, including a low-power mode, to ensure power efficiency for battery-powered and power-sensitive applications.
• Package: Available in a 64-pin LQFP package, ensuring a compact footprint for space-constrained applications.

Applications

The STM32F103RCT6TR is designed for a wide range of applications, including industrial control systems, motor drives, medical and handheld equipment, PC peripherals, gaming and GPS platforms, alarm systems, video intercom, and HVACs. Its robust design and rich set of peripherals make it an ideal choice for applications that require high-speed operation, real-time capabilities, and multiple connectivity options.

As a product of STMicroelectronics, a global semiconductor leader, the STM32F103RCT6TR benefits from the company's commitment to continuous innovation and its strong support ecosystem. Developers can take advantage of extensive development tools and software libraries provided by ST to streamline product development and reduce time to market.
