Products specifications

Category Integrated Circuits (ICs)>PMIC - Voltage Regulators - Linear
Mfr STMicroelectronics
Package Tape & Reel
Output Configuration Positive
Output Type Fixed
Number of Regulators 1
Voltage - Input (Max) 5.5V
Voltage - Output (Min/Fixed) 1.2V
Voltage Dropout (Max) 0.49V @ 300mA
Current - Output 300mA
Current - Quiescent (Iq) 40 µA
Current - Supply (Max) 305 µA
PSRR 75dB ~ 55dB (1kHz ~ 100kHz)
Control Features Enable, Soft Start
Protection Features Over Temperature
Temperature Range - Operating -40°C ~ 125°C (TJ)
Mounting SMD (SMT)
Package / Case 4-XDFN Exposed Pad
Supplier Device Package 4-DFN (1x1)
Base Product Number LD59030
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names -1138-LD59030DTPU12RTR,497-18219-2,497-18219-1,-1138-LD59030DTPU12RCT,LD59030DTPU12R-ND,-1138-LD59030DTPU12RDKR,497-18219-6
Standard Package 5,000
Win Source Part Number 1069173-LD59030DTPU12R
Ultra Librarian 3D Model Ultra Librarian LD59030DTPU12R CAD Model

Description

Introducing the LD59030DTPU12R Voltage Regulator by STMicroelectronics

The LD59030DTPU12R is a high-performance, low-dropout voltage regulator designed by STMicroelectronics, a leader in semiconductor solutions. This state-of-the-art component is ideal for a wide range of applications, including consumer electronics, automotive systems, and industrial equipment, providing a reliable and efficient power supply solution.

Key Features

  • Output Voltage: The LD59030DTPU12R provides a stable 1.2V output, which is essential for powering sensitive electronic circuits.
  • High Current Capability: With an output current capability of up to 3A, this voltage regulator can easily handle high-power applications.
  • Low Dropout Voltage: The low dropout feature ensures efficient operation even when the input voltage is very close to the output voltage, reducing power loss and improving overall system efficiency.
  • Thermal Protection: Built-in thermal shutdown protection prevents damage from overheating, enhancing the longevity and reliability of both the regulator and the system it powers.
  • Current Limiting: The device also includes current limiting features to protect against short-circuit and overload conditions.
  • Package: The LD59030DTPU12R comes in a DFN10 (3x3 mm) package, which is compact and suitable for space-constrained applications.

Applications

The versatility of the LD59030DTPU12R allows it to be used in a variety of settings. It can be integrated into:

  • Battery-powered devices where power efficiency is critical
  • Microprocessor and microcontroller systems that require a stable voltage supply
  • Automotive electronics that must withstand fluctuating input voltages and harsh conditions
  • Industrial equipment demanding high reliability and performance

Quality and Reliability

STMicroelectronics is renowned for their commitment to quality, and the LD59030DTPU12R is no exception. It is designed to meet the stringent requirements of various industries, ensuring that your product operates reliably over its intended lifespan. With the LD59030DTPU12R, you can expect a product that performs consistently, providing the power stability your applications need.

For detailed specifications and application notes, visit the STMicroelectronics website or contact their support team for further assistance.
