Name: SSQ-115-02-S-S-RA
Brand: Samtec Inc.
SKU: 1288990
Availability: InStock
Rating: 4.85 (5 reviews)

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr	Samtec Inc.
Series	SSQ
Package	Bulk
Connector Type	Receptacle
Contact Type	Forked
Style	Board to Board or Cable
Number of Positions	15
Number of Positions Loaded	All
Pitch - Mating	0.100" (2.54mm)
Number of Rows	1
Mounting Type	Through Hole, Right Angle
Termination	Solder
Fastening Type	Push-Pull
Contact Finish - Mating	Gold
Contact Finish Thickness - Mating	30.0µin (0.76µm)
Insulation Color	Black
Insulation Height	0.095" (2.41mm)
Contact Length - Post	0.100" (2.54mm)
Temperature Range - Operating	-55°C ~ 125°C
Material Flammability Rating	UL94 V-0
Contact Finish - Post	Tin
Voltage Rating	465VAC, 655VDC
Insulation Material	Liquid Crystal Polymer (LCP)
Contact Shape	Square
Contact Material	Phosphor Bronze
Base Product Number	SSQ-115
Other Names	SAM1192-15
Standard Package	1
MSL Level	Not Applicable
REACH Status	REACH Unaffected
ECCN	EAR99
HTSUS	8536.69.4040
Win Source Part Number	1288990-SSQ-115-02-S-S-RA
Ultra Librarian 3D Model	Ultra Librarian SSQ-115-02-S-S-RA CAD Model

Description

The SSQ series from Samtec Inc. is a high-quality connector designed for rectangular connectors - headers, receptacles, female sockets.

Connector Type: Receptacle
Contact Type: Forked
Positions Loaded: All positions
Number of Rows: One
Termination: Solder
Fastening Type: Push-Pull
Contact Material: Phosphor Bronze
Voltage Rating: 465VAC, 655VDC
Insulation Material: Liquid Crystal Polymer (LCP)
Insulation Height: 0.095" (2.41mm)
Pitch for Mating: 0.100" (2.54mm)
Contact Finish for Mating: Gold
Contact Finish Thickness for Mating: 30.0μin (0.76μm)
Contact Finish for Post: Tin
Application: Board-to-board or cable style
Mounting Type: Through-hole, Right-angle
Contact Length for Post: 0.100" (2.54mm)
Contact Shape: Square
Operating Temperature Range: -55°C to 125°C
