Part No SFMC-115-02-L-D-P-TR
Manufacturer Samtec Inc.
Catalog Rectangular Connectors
Datasheet
SFMC-115-02-L-D-P-TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Receptacles, Female Sockets
Mfr Samtec Inc.
Series Tiger Eye™ SFMC
Package Tape & Reel (TR)
Connector Type Receptacle
Contact Type Female Socket
Style Board to Board or Cable
Number of Positions 30
Number of Positions Loaded All
Pitch - Mating 0.050" (1.27mm)
Number of Rows 2
Row Spacing - Mating 0.050" (1.27mm)
Mounting SMD (SMT)
Termination Solder
Fastening Type Push-Pull
Contact Finish - Mating Gold
Contact Finish Thickness - Mating 10.0µin (0.25µm)
Insulation Color Black
Insulation Height 0.185" (4.70mm)
Temperature Range - Operating -55°C ~ 125°C
Material Flammability Rating UL94 V-0
Contact Finish - Post Tin
Features Pick and Place
Current Rating (Amps) 2.9A per Contact
Insulation Material Liquid Crystal Polymer (LCP)
Contact Shape Square
Contact Material Beryllium Copper
Base Product Number SFMC-115
Standard Package 425
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1286514-SFMC-115-02-L-D-P-TR
Ultra Librarian 3D Model Ultra Librarian SFMC-115-02-L-D-P-TR CAD Model

Description

The SFMC-115-02-L-D-P-TR is a rectangular connector manufactured by Samtec Inc.

  • Win Source Part Number: 1286514-SFMC-115-02-L-D-P-TR
  • Category: connectors, interconnects>rectangular connectors - headers, receptacles, female sockets
  • Series: Tiger Eye™ SFMC
  • Number of positions: 30
  • Connector type: receptacle
  • Contact type: female socket
  • Number of positions loaded: all
  • Number of rows: 2
  • Termination: solder
  • Fastening type: push-pull
  • Package: tape & reel (TR)
  • Contact material: beryllium copper
  • Voltage rating: not specified
  • Insulation material: liquid crystal polymer (LCP)
  • Style: board to board or cable
  • Pitch - mating: 0.050" (1.27mm)
  • Contact finish - mating: gold
  • Contact finish thickness - mating: 10.0µin (0.25µm)
  • Contact finish - post: tin
  • Contact finish thickness - post: not specified
  • Insulation color: black
  • Row spacing - mating: 0.050" (1.27mm)
  • Contact length - post: not specified
  • Insulation height: 0.185" (4.70mm)
  • Contact shape: square
  • Temperature range - operating: -55°C ~ 125°C
