The SSA series SSA-129-W-T-RA receptacle connector from Samtec Inc. features 29 positions, 1 row, and female socket contact type.

• Positions: 29
• Row: 1
• Contact Type: Female Socket
• Connection Style: Board to Board
• Pitch: 0.100" (2.54mm)
• Voltage Rating: 1000V
• Contact Material: Phosphor Bronze
• Contact Plating (Mating): Tin
• Termination: Through Hole
• Fastening Type: Push-Pull
• Temperature Range: -55°C ~ 105°C
• Material Flammability Rating: UL94 V-0
• Package: Bulk
• Breakaway: Yes
• Insulation Material: Polyethylene Terephthalate (PET), Polyester
• Insulation Height: 0.100" (2.54mm)
• Mounting Type: Right Angle
• Contact Length for Post: 0.575" (14.61mm)
