FSMD110-16-R Fuzetec FSMD110-16-R Real Image FSMD110-16-R label picture 2 FSMD110-16-R label picture 3 FSMD110-16-R label picture 4
Same model may have multiple batches, images only for reference.
FSMD110-16-R Fuzetec FSMD110-16-R Real Image FSMD110-16-R label picture 2 FSMD110-16-R label picture 3 FSMD110-16-R label picture 4
FSMD110-16-R Fuzetec FSMD110-16-R Real Image FSMD110-16-R label picture 2 FSMD110-16-R label picture 3 FSMD110-16-R label picture 4
Same model may have multiple batches, images only for reference.

FSMD110-16-R

Part No FSMD110-16-R
Manufacturer RFE/Fuzetec
Catalog PTC Resettable Fuses
Description RESETTABLE FUSE - SMD, 1812 SIZE
Datasheet
FSMD110-16-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Circuit Protection - PTC Resettable Fuses
Mfr RFE/Fuzetec
Series FSMD1812
Package Tape & Reel
Product Status Active
Voltage - Max 16V
Current - Hold (Ih) (Max) 1.1 A
Current - Trip (It) 2.2 A
Current - Max 100 A
Time to Trip 500 ms
Resistance - Initial (Ri) (Min) 60 mOhms
Resistance - Post Trip (R1) (Max) 180 mOhms
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 1812 (4532 Metric), Concave
Size / Dimension 0.179" L x 0.128" W (4.55mm x 3.24mm)
Thickness (Max) 0.035" (0.90mm)
Approval Agency cUL, TUV, UL
Standard Package 50 pcs
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8533.40.8070
Win Source Part Number 133497-FSMD110-16-R
Ultra Librarian 3D Model Ultra Librarian FSMD110-16-R CAD Model

Description

The FSMD110-16-R (Part Number: 133497-FSMD110-16-R) is a PTC resettable fuse from the FSMD1812 series.

  • Maximum Voltage Rating: 16V
  • Maximum Current Rating: 100A
  • Size: 0.179" L x 0.128" W (4.55mm x 3.24mm)
  • Thickness: 0.035" (0.90mm)
  • Package: Tape and Reel
  • Approvals: cUL, TUV, and UL
