Same model may have multiple batches, images only for reference.
RF2369 Real Image
Same model may have multiple batches, images only for reference.

RF2369

Part No RF2369
Manufacturer RF Micro Devices
Catalog Coaxial Cables (RF)
Description SMA BULKHEAD JACK-AMC PLUG 200MM
Datasheet
RF2369 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Cable Assemblies
Manufacturer Amphenol RF Division
Status Active
Gender Female to Female
Style SMA to UMC
1st Connector SMA Female Jack
2nd Connector Ultra Miniature Coaxial Plug Female Socket, Right Angle
Length 7.874" (200.00mm)
Cable Type 1.32mm OD Coaxial Cable
Impedance 50 Ohm
Maximum Input Frequency 6GHz
Win Source Part Number 293349-RF2369
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RF2369 CAD Model

Description

The RF2369 is a cable assembly from Amphenol RF Division.

  • Gender: female to female
  • Length: 7.874 inches (200.00mm)
  • Cable Type: 1.32mm OD coaxial cable
  • Impedance: 50 Ohm
  • Style: SMA to UMC
  • First Connector: SMA female jack
  • Second Connector: ultra-miniature coaxial plug female socket, right angle
  • Maximum Input Frequency: 6GHz
  • Supply and Demand Status: balance
