AQZ262 Nais(Matsushita Electric Works)
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Relays - Solid State Relays
Mfr Panasonic
Series PhotoMOS™ AQZ
Package Box
Product Status Obsolete
Mounting Type Through Hole
Circuit SPST-NO (1 Form A)
Output Type AC, DC
Voltage - Input 1.16VDC
Voltage - Load 0 V ~ 60 V
Load Current 6 A
On-State Resistance (Max) 50 mOhms
Termination Style PC Pin
Package / Case 4-SIP
Supplier Device Package 4-SIL
Base Product Number AQZ26
Standard Package 20 pcs
Moisture Sensitivity Level (MSL) Not Applicable
ECCN EAR99
HTSUS 8536.41.0030
Win Source Part Number 564492-AQZ262
Ultra Librarian 3D Model Ultra Librarian AQZ262 CAD Model

Description

The PhotoMOS™ AQZ262 is a solid-state relay with a SPST-NO (1 Form A) circuit configuration. It is capable of handling load currents of up to 6 A and voltages ranging from 0 V to 60 V.

  • Input Voltage: 1.16VDC
  • Output Type: AC and DC
  • Maximum On-State Resistance: 50 mOhms
  • Mounting Type: Through-Hole
  • Package: 4-SIP
  • Series: PhotoMOS™ AQZ
  • Manufacturer: Panasonic
  • Package Quantity: 20 pieces
  • Package Type: Box
  • Product Status: Obsolete
  • Category: Electronic Components
