NRF24AP2-1CHQ32-R Real Image NRF24AP2-1CHQ32-R real image10806
Same model may have multiple batches, images only for reference.
NRF24AP2-1CHQ32-R Real Image NRF24AP2-1CHQ32-R real image10806
NRF24AP2-1CHQ32-R Real Image NRF24AP2-1CHQ32-R real image10806
Same model may have multiple batches, images only for reference.

NRF24AP2-1CHQ32-R

Part No NRF24AP2-1CHQ32-R
Manufacturer Nordic Semiconductors
Catalog RF Transceiver ICs
Description IC RF TXRX ISM>1GHZ 32-VFQFN
Datasheet
NRF24AP2-1CHQ32-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Nordic Semiconductor ASA
Packaging Reel - TR
Status Active
Type TxRx Only
RF Family/Standard General ISM > 1GHZ
Protocol ANT
Modulation GFSK
Frequency 2.4GHz
Data Rate (Max) 1Mbps
Power - Output 0dBm
Sensitivity -85dBm
Serial Interfaces USART
Supply Voltage - Operating 1.9 V to 3.6 V
Current - Receiving 17mA
Current - Transmitting 11mA to 15mA
Temperature Range - Operating -40°C to 85°C
Dimension 32-VFQFN Exposed Pad
Win Source Part Number 1083409-NRF24AP2-1CHQ32-R
Popularity Medium
Supply and Demand Status Balance
Quantity per package 4k pcs
Ultra Librarian 3D Model Ultra Librarian NRF24AP2-1CHQ32-R CAD Model

Description

The Nordic Semiconductor ASA NRF24AP2-1CHQ32-R is a high-performance transceiver suitable for use in various electronic applications.

  • Frequency: 2.4GHz
  • Protocol: ANT
  • Maximum Data Rate: 1Mbps
  • Sensitivity: -85dBm
  • Category: RF/IF and RFID
  • Temperature Range: -40°C to 85°C
  • Operating Voltage: 1.9V to 3.6V
