BZT52H-C9V1,115 Nexperia USA Inc. BZT52H-C9V1,115 label picture
Same model may have multiple batches, images only for reference.
BZT52H-C9V1,115 Nexperia USA Inc. BZT52H-C9V1,115 label picture
BZT52H-C9V1,115 Nexperia USA Inc. BZT52H-C9V1,115 label picture
Same model may have multiple batches, images only for reference.

BZT52H-C9V1,115

Part No BZT52H-C9V1,115
Manufacturer Nexperia USA Inc.
Catalog Diodes - Zener - Single
Description DIODE ZENER 9.1V 375MW SOD123F
Datasheet
BZT52H-C9V1,115 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Voltage - Zener (Nom) (Vz) 9.1V
Tolerance ±5%
Maximum Power Dissipation 375mW
Impedance (Max) (Zzt) 10 Ohm
Current - Reverse Leakage @ Vr 500nA @ 6V
Voltage - Forward (Vf) (Max) @ If 900mV @ 10mA
Temperature Range - Operating -65°C to 150°C
Mounting SMD (SMT)
Case / Package SOD-123F
Win Source Part Number 1026077-BZT52H-C9V1,115
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian BZT52H-C9V1,115 CAD Model

Description

The BZT52H-C9V1,115 is a Zener diode manufactured by Nexperia USA Inc.

  • Forward Voltage: 900mV @ 10mA
  • Reverse Leakage Current: 500nA @ 6V
  • Nominal Voltage: 9.1V
  • Impedance (Max): 10 Ohm
  • Mounting Type: SMD (SMT)
  • Package: SOD-123F
  • Power Dissipation (Max): 375mW
  • Category: Discrete Semiconductor Products
  • Operating Temperature: -65°C to 150°C
  • Popularity: Medium
  • Supply and Demand: Medium
