90325-9008 Real Image
Same model may have multiple batches, images only for reference.

90325-9008

Part No 90325-9008
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Shrouded Header HDR 8 POS 1.5mm Solder RA Thru-Hole Loose Piece
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Blade Pin
Contact Gender Male
Contact Material Brass
Contact Plating Tin
Contact Resistance 15 mΩ
Country of Origin MY
Current Rating 1.2 A
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Polyester
Lead Free Yes
Lead Length 3.3 mm
Lead Pitch 1.27 mm
Maximum Operating Temperature 105 °C
Min Operating Temperature -40 °C
Mount Through Hole
Number of Circuits 8
Number of Contacts 8
Number of Pins 8
Number of Positions 8
Number of Rows 1
Orientation Vertical
Pitch 1.27 mm
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Win Source Part Number 1032021-90325-9008
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 90325-9008 CAD Model

Description

This Molex Circular Connector Housing is a male connector with 8 contacts and a pitch of 1.27 mm.

  • Connector Type: Male
  • Contacts: 8
  • Pitch: 1.27 mm
  • Contact Material: Brass
  • Termination: Solder
  • Voltage Rating: 250 V
  • Current Rating: 1.2 A
  • Housing Material: Polyester
  • Housing Color: Black
  • Contact Plating: Tin
  • RoHS Compliant: Yes
  • Maximum Operating Temperature: 105 °C
  • Suitable for: Electronics Applications
