54722-0164 Real Image
Same model may have multiple batches, images only for reference.

54722-0164

Part No 54722-0164
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description SLIMSTACK Series 0.5mm 16 Way 2 Row Straight PCB Socket Smnt Board to Board
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Case / Package 0164
Contact Material Bronze
Contact Plating Gold
Country of Origin JP
Current Rating 300 mA
ELV Compliant
Gender Receptacle
Glow Wire Compliant Non-compliant
Halogen Free Low Halogen
Housing Material Thermoplastic
Material Bronze
Max Operating Temperature 85 °C
Min Operating Temperature -25 °C
Mount Surface Mount
Number of Circuits 16
Number of Contacts 16
Number of Positions 16
Number of Rows 2
Orientation Vertical
Packaging Tape & Reel
Pitch 500 µm
Plating Gold
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Stack Height 1.5 mm
Termination SMD/SMT
Voltage Rating 50 V
Win Source Part Number 1156084-54722-0164
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 54722-0164 CAD Model

Description

The Molex 1156084-54722-0164 is a 16-position, 2-row, vertical receptacle connector with a pitch of 500 µm.

  • Voltage Rating: 50 V
  • Current Rating: 300 mA
  • Contact Material: bronze
  • Contact Plating: gold
  • Housing Material: thermoplastic
  • Stack Height: 1.5 mm
  • Mounting Type: surface mountable
  • RoHS Compliant: Yes
  • Application: Widely used in circular connector housings.
