22-28-4040 Real Image
Same model may have multiple batches, images only for reference.

22-28-4040

Part No 22-28-4040
Manufacturer Molex, LLC
Catalog Circular Connectors - Housings
Description Conn Unshrouded Header HDR 4 POS 2.54mm Solder ST Top Entry Thru-Hole Carton
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Color Black
Connector Type Male Pin
Contact Material Brass
Contact Mating Length 6.096 mm
Contact Plating Tin
Contact Resistance 20 mΩ
Country of Origin US
Current Rating 4 A
Depth 2.49 mm
Gender Male
Glow Wire Compliant Non-compliant
Housing Color Black
Housing Material Thermoplastic
Lead Free Yes
Length 10.16 mm
Maximum Operating Temperature 75 °C
Max Voltage Rating (AC) 250 V
Max Voltage Rating (DC) 250.25 kV
Min Operating Temperature 0 °C
Mount Through Hole
Number of Circuits 4
Number of Contacts 4
Number of Positions 4
Number of Rows 1
Orientation Vertical
Packaging Bulk
Pitch 2.54 mm
Plating Tin
Radiation Hardening No
REACH SVHC Unknown
RoHS Compliant
Termination Solder
Voltage Rating 250 V
Win Source Part Number 1040720-22-28-4040
Categories Circular Connectors - Housings
Manufacturer Molex, LLC
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian 22-28-4040 CAD Model

Description

The Molex Circular Connectors - Housings is a product used in a variety of electronic applications.

  • Manufacturer: Molex, LLC
  • Package: Bulk
  • ECCN: EAR99
  • RoHS Compliant: Yes
