Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Memory - Memory
Mfr Macronix
Series MXSMIO™
Package Tape & Reel
Product Status Not For New Designs
Programmable Not Verified
Memory Type Non-Volatile
Memory Format FLASH
Technology FLASH - NOR
Memory Size 64Mbit
Memory Organization 8M x 8
Memory Interface SPI - Quad I/O
Clock Frequency 80 MHz
Write Cycle Time - Word, Page 100µs, 10ms
Voltage - Supply 1.65V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C (TA)
Mounting Type Surface Mount
Package / Case 22-UFBGA, WLCSP
Supplier Device Package 22-WLCSP
Base Product Number MX25R6435
Standard Package 6,000 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A991B1A
HTSUS 8542.32.0071
Win Source Part Number 806364-MX25R6435FBDIL0
Ultra Librarian 3D Model Ultra Librarian MX25R6435FBDIL0 CAD Model

Description

The MX25R6435FBDIL0 is a 64Mbit FLASH - NOR memory integrated circuit (IC) from Macronix.

  • Series: MXSMIO™
  • Package: 22-UFBGA, WLCSP
  • Voltage Supply: 1.65V to 3.6V
  • Clock Frequency: 80 MHz
  • Temperature Range: -40°C to 85°C
  • Memory Size: 64Mbit
  • Memory Organization: 8M x 8
  • Memory Interface: SPI - Quad I/O
  • Write Cycle Time: 100μs (word), 10ms (page)
  • Programmable: No
  • Memory Application: Memory
