S7B-XH-A(LF)(SN) Real Image
Same model may have multiple batches, images only for reference.

S7B-XH-A(LF)(SN)

Part No S7B-XH-A(LF)(SN)
Manufacturer JST Sales America Inc.
Catalog FFC, FPC (FlatFlexible) Connectors
Description CONN HEADER R/A 7POS 2.5MM / Connector Header Through Hole, Right Angle 7 position 0.098" (2.50mm)
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr JST Sales America Inc.
Series XH
Package Bulk
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.098" (2.50mm)
Number of Positions 7
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Through Hole, Right Angle
Termination Press-Fit, Solder
Fastening Type Detent Lock
Contact Length - Post 0.134" (3.40mm)
Insulation Height 0.240" (6.10mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA66), Nylon 6/6
Temperature Range - Operating -25°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Natural
Current Rating (Amps) 3A
Voltage Rating 250V
Base Product Number S7B-XH-A
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names (G)S7B-XH-A(LF)(SN),S7BXHALFSN,455-2240
Standard Package 250
Win Source Part Number 1090346-S7B-XH-A(LF)(SN)
Ultra Librarian 3D Model Ultra Librarian S7B-XH-A(LF)(SN) CAD Model

Description

The JST Sales America Inc. S7B-XH-A(LF)(SN) is a rectangular connector designed for use in board to cable/wire applications.

  • Positions: 7
  • Type: Male pin header
  • Voltage Rating: 250V
  • Current Rating: 3A
  • Contact Material: Brass
  • Contact Finish: Tin
  • Temperature Range: -25°C to 85°C
  • Package: Shrouded - 4 wall
  • Packaging: Bulk
  • Standard Package: 250
