TDA5255XUMA1 Real Image TDA5255XUMA1 real image
Same model may have multiple batches, images only for reference.
TDA5255XUMA1 Real Image TDA5255XUMA1 real image
TDA5255XUMA1 Real Image TDA5255XUMA1 real image
Same model may have multiple batches, images only for reference.

TDA5255XUMA1

Part No TDA5255XUMA1
Manufacturer Infineon Technologies
Catalog RF Transceiver ICs
Description IC RF TXRX ISM
Datasheet
TDA5255XUMA1 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Infineon Technologies
Packaging Reel - TR
Status Obsolete(EOL)
Type TxRx Only
RF Family/Standard General ISM
Modulation ASK, FSK
Frequency 434MHz
Data Rate (Max) 100kbps
Power - Output 13dBm
Sensitivity -109dBm
Serial Interfaces I2C, SPI
Supply Voltage - Operating 2.1 V to 5.5 V
Current - Receiving 8.6mA to 9.5mA
Current - Transmitting 5.2mA to 17.4mA
Temperature Range - Operating -40°C to 85°C
Dimension 38-TFSOP (0.173", 4.40mm Width)
Win Source Part Number 127771-TDA5255XUMA1
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TDA5255XUMA1 CAD Model

Description

The Infineon Technologies 369269 is an RF/IF and RFID product, specifically a TxRx Only device.

  • Frequency: 434MHz
  • Data Rate (Max): 100kbps
  • Sensitivity: -109dBm
  • Output Power: 13dBm
  • Current - Receiving: 8.6mA to 9.5mA
  • Current - Transmitting: 5.2mA to 17.4mA
  • Modulation Types: ASK and FSK
  • Packaging: Reel - TR
  • Case / Package: 38-TFSOP (0.173", 4.40mm Width)
  • Supply Voltage: 2.1 V to 5.5 V
  • Category: RF/IF and RFID
  • Status: Obsolete(EOL)
  • Temperature Range: -40°C to 85°C
  • Supply and Demand Status: balanced
