IRG8P60N120KD-EPBF

Part No IRG8P60N120KD-EPBF
Manufacturer Infineon Technologies
Catalog IGBTs - Single
Description IGBT 1200V 100A TO-247AD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Product Status Obsolete
Voltage - Collector Emitter Breakdown (Max) 1200 V
Current - Collector (Ic) (Max) 100 A
Current - Collector Pulsed (Icm) 120 A
Vce(on) (Max) @ Vge, Ic 2V @ 15V, 40A
Power - Max 420 W
Switching Energy 2.8mJ (on), 2.3mJ (off)
Input Type Standard
Gate Charge 345 nC
Td (on/off) @ 25°C 40ns/240ns
Test Condition 600V, 40A, 5Ohm, 15V
Reverse Recovery Time (trr) 210 ns
Temperature Range - Operating -40°C ~ 150°C (TJ)
Mounting Type Through Hole
Case / Package TO-247-3
Supplier Device Package TO-247AD
Package Bulk
Supply and Demand Status Normal
Win Source Part Number 1495013-IRG8P60N120KD-EPBF
Ultra Librarian 3D Model Ultra Librarian IRG8P60N120KD-EPBF CAD Model
