FH41-40S-0.5SH(05) Real Image
Same model may have multiple batches, images only for reference.

FH41-40S-0.5SH(05)

Part No FH41-40S-0.5SH(05)
Manufacturer Hirose Electric Co Ltd
Catalog FFC, FPC (FlatFlexible) Connectors
Description CONN FFC BOTTOM 40POS 0.50MM R/A
Datasheet
FH41-40S-0.5SH(05) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Hirose Electric Co Ltd
Packaging Reel - TR
Status Active
Flat Flex Type FFC
Mounting Surface Mount, Right Angle
Connector/Contact Type Contacts, Bottom
Number of Positions 40
Pitch 0.020" (0.50mm)
Termination Solder
FFC, FCB Thickness 0.30mm
Height Above Board 0.098" (2.50mm)
Locking Feature Flip Lock, Backlock
Cable End Type Tabbed
Contact Finish Gold
Housing Material Liquid Crystal Polymer (LCP), Halogen Free
Actuator Material Liquid Crystal Polymer (LCP), Halogen Free
Features Solder Retention
Voltage Rating 50V
Temperature Range - Operating -40°C to 105°C
Material Flammability Rating UL94 V-0
Current Rating 0.5A
Contact Finish Thickness 1.25μin (0.03μm)
Housing Color Gray
Actuator Color Black
Mating Cycles 20
Win Source Part Number 1038826-FH41-40S-0.5SH(05)
Popularity Medium
Supply and Demand Status Balance
Application Field Used in Industrial
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian FH41-40S-0.5SH(05) CAD Model

Description

The Hirose Electric Co Ltd FH41 connector series is a 40-position, 0.020" (0.50mm) pitch, surface-mount, right-angle connector that offers solder retention.

  • Series: FH41
  • Number of Positions: 40
  • Pitch: 0.020" (0.50mm)
  • Mounting Type: Surface Mount
  • Angle: Right Angle
  • Solder Retention: Yes
  • Locking Feature: Flip Lock, Backlock
  • Current Rating: 0.5A
  • Voltage Rating: 50V
  • Contact Finish: Gold
  • Contact Finish Thickness: 1.25μin (0.03μm)
  • Contact Material: Phosphor Bronze
  • Housing and Actuator Material: Liquid Crystal Polymer (LCP), Halogen-Free
  • Height Above Board: 0.098" (2.50mm)
  • Application: FFC Flat Flex Type
  • Mating Cycles: 20
  • Part Status: Active
  • Supply and Demand Status: Balance
  • Quantity per Package: 2,500
