DF13A-6P-1.25H(21) Real Image
Same model may have multiple batches, images only for reference.

DF13A-6P-1.25H(21)

Part No DF13A-6P-1.25H(21)
Manufacturer Hirose Electric Co Ltd
Catalog Circular Connectors - Housings
Description CONN HEADER SMD R/A 6POS 1.25MM / Connector Header Surface Mount, Right Angle 6 position 0.049" (1.25mm)
Datasheet
DF13A-6P-1.25H(21) Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>Rectangular Connectors - Headers, Male Pins
Mfr Hirose Electric Co Ltd
Series DF13
Package Tape & Reel
Connector Type Header
Contact Type Male Pin
Pitch - Mating 0.049" (1.25mm)
Number of Positions 6
Number of Rows 1
Number of Positions Loaded All
Style Board to Cable/Wire
Shrouding Shrouded - 4 Wall
Mounting Type Surface Mount, Right Angle
Termination Solder
Fastening Type Detent Lock
Insulation Height 0.142" (3.60mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish - Post Tin
Contact Material Brass
Insulation Material Polyamide (PA), Nylon
Features Solder Retention
Temperature Range - Operating -35°C ~ 85°C
Material Flammability Rating UL94 V-0
Insulation Color Beige
Current Rating (Amps) 1A
Voltage Rating 150V
Base Product Number DF13A
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names H125991DKR,DF13A-6P-1.25H(21)-ND,H125991CT,H125991TR,536-0305-9-21
Standard Package 1,000
Win Source Part Number 999033-DF13A-6P-1.25H(21)
Ultra Librarian 3D Model Ultra Librarian DF13A-6P-1.25H(21) CAD Model

Description

The Hirose Electric Co Ltd DF13A-6P-1.25H(21) is a rectangular connector that is designed for use in board to cable/wire applications.

  • Current Rating: 1A
  • Voltage Rating: 150V
  • Package: Tape and Reel
  • Mounting: Surface Mount
