MOCD223R2VM Real Image MOCD223R2VM real image10745
Same model may have multiple batches, images only for reference.
MOCD223R2VM Real Image MOCD223R2VM real image10745
MOCD223R2VM Real Image MOCD223R2VM real image10745
Same model may have multiple batches, images only for reference.

MOCD223R2VM

Part No MOCD223R2VM
Manufacturer Fairchild/ON Semiconductor
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISOLTR 2.5KV 2CH DARL 8SOIC
Datasheet
MOCD223R2VM Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Fairchild/ON Semiconductor
Packaging Reel - TR
Status Active
Number of Channels 2
Isolation Voltage 2500Vrms
Minimum DC Current Transfer Ratio 500% @ 1mA
Switching Turn-On and Turn-Off Time 10μs, 125μs
Rise and Fall Time 8μs, 110μs
Input Type DC
Output Type Darlington
Maximum Output Voltage 30V
Channel Output Current 150mA
Forward Voltage 1.25V
Continuous forward current- Max 60mA
Vce Saturation (Max) 1V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 8-SO Tall
Win Source Part Number 1078786-MOCD223R2VM
Popularity Medium
Supply and Demand Status Limited
Quantity per package 2,500
Ultra Librarian 3D Model Ultra Librarian MOCD223R2VM CAD Model

Description

The Fairchild/ON Semiconductor MOCD223R2VM is a Darlington output type isolator.

  • Forward Voltage: 1.25V
  • Input Type: DC
  • Channels: Two
  • Vce Saturation (Max): 1V
  • Isolation Voltage: 2500Vrms
  • Package: 8-SO Tall
  • Minimum DC Current Transfer Ratio: 500% @ 1mA
  • Switching Turn-On Time: 10μs
  • Switching Turn-Off Time: 125μs
  • Rise Time: 8μs
  • Fall Time: 110μs
  • Maximum Output Voltage: 30V
  • Channel Output Current: 150mA
  • Continuous Forward Current-Max: 60mA
  • Supply and Demand: limited
  • Quantity per Package: 2,500
