SG-615PH 38.0000MC0

Part No SG-615PH 38.0000MC0
Manufacturer Epson Electronics America Inc-Semiconductor Div
Catalog Oscillators
Description OSC XO 38.000MHZ CMOS SMD
Datasheet
SG-615PH 38.0000MC0 Datasheet
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Crystals, Oscillators, Resonators
Manufacturer EPSON
Packaging Reel - TR
Status Obsolete(EOL)
Type XO (Standard)
Frequency 38MHz
Purpose Enable/Disable
Output CMOS
Supply Voltage - Operating 5V
Frequency Stability ±100ppm
Temperature Range - Operating -20°C to 70°C
Current - Supply (Max) 35mA
Mounting SMD (SMT)
Dimension 0.551" L x 0.341" W (14.00mm x 8.65mm)
Height - Seated (Max) 0.185" (4.70mm)
Current - Supply (Disable) (Max) 20mA
Win Source Part Number 125710-SG-615PH 38.0000MC0
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SG-615PH 38.0000MC0 CAD Model

Description

The EPSON SG-615PH 38. It belongs to the XO (Standard) type and is supplied in a reel - TR package with a height - seated (max) of 0.185" (4.70mm) and mounting SMD (SMT).

  • Frequency: 38MHz
  • Output: CMOS
  • Frequency Stability: ±100ppm
  • Current - Supply (Max): 35mA
  • Current - Supply (Disable) (Max): 20mA
  • Temperature Range - Operating: -20°C to 70°C
  • Dimension: 0.551" L x 0.341" W (14.00mm x 8.65mm)
  • Purpose: Enable/Disable
  • Supply Voltage - Operating: 5V
