FP0705R1-R15-R

Part No FP0705R1-R15-R
Manufacturer Eaton Bussmann
Catalog Fixed Inductors
Description FIXED IND 150NH 43A 0.25MOHM SMD
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number Cross
Manufacturer Eaton - Electronics Division
Category Inductors, Coils, Chokes Fixed Inductors
Part Status Active
Type Drum Core, Wirewound
Inductance 150 nH
Tolerance ±10%
DC Resistance (DCR) 0.25mOhm
Operating Temperature -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Win Source Part Number WS1305699-FP0705R1-R15-R
Ultra Librarian 3D Model Ultra Librarian FP0705R1-R15-R CAD Model

Description

Product features
• High current carrying capacity
• Low core loss
• Inductance Range from 72 nH to 220 nH
• Current range from 20 A to 65 A
• 7.0 mm x 7.0 mm footprint surface mount package in a 4.95 mm height
• Ferrite core material
• Halogen free, lead free, RoHS compliant
