S29AL004D90TFI020 Cypress Semiconductor Corp S29AL004D90TFI020 real image5256
Same model may have multiple batches, images only for reference.
S29AL004D90TFI020 Cypress Semiconductor Corp S29AL004D90TFI020 real image5256
S29AL004D90TFI020 Cypress Semiconductor Corp S29AL004D90TFI020 real image5256
Same model may have multiple batches, images only for reference.

S29AL004D90TFI020

Part No S29AL004D90TFI020
Manufacturer Cypress Semiconductor Corp
Catalog Flash
Description 4 Megabit (512 Kx 8-Bit/256 K x 16-Bit) CMOS 3.0 Volt-only Boot Sector Flash Memory
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Cypress Semiconductor Corp
Density 4194304(Bit)
Package Type TSOP
Supply Current 16(mA)
Interface Type Parallel
Packaging Tray
Operating Supply Voltage (Max) 3.6(V)
Operating Supply Voltage (Min) 2.7(V)
Operating Temperature (Min) -40C
Programmable Yes
Mounting Surface Mount
Pin Count 48
Number of Words 512K/256K
Program/Erase Volt (Typ) 2.7 to 3.6(V)
Operating Temp Range -40C to 85C
Rad Hardened No
Access Time (Max) 90(ns)
Operating Temperature (Max) 85C
Sync/Async Asynchronous
Operating Temperature Classification Industrial
Operating Supply Voltage (Typ) 3/3.3(V)
Boot Type Bottom
Cell Type NOR
Win Source Part Number 046558-S29AL004D90TFI020
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian S29AL004D90TFI020 CAD Model

Description

The Cypress Semiconductor Corp S29AL004D90TFI020 is a 4194304-bit density asynchronous NOR flash memory with 512K/256K number of words.

  • Supply Voltage Range: 2.7V to 3.6V
  • Supply Current: 16mA
  • Operating Temperature (Max): 85C
  • Operating Temperature (Min): -40C
  • Package: TSOP
  • Mounting: Surface-mountable
  • Programmable: Yes
  • Boot Type: Bottom
  • Interface Type: Parallel
  • Access Time: 90ns
  • Grade: Industrial
  • Rad-Hardened: No
  • Supply and Demand Status: Balanced
