The CYBL10561-56LQXI is a highly integrated, low-power Bluetooth Low Energy (BLE) system-on-chip (SoC) from Cypress Semiconductor Corp. It is designed for a wide range of applications requiring short-range wireless connectivity. This BLE SoC integrates a 2.4 GHz radio transceiver, a 32-bit ARM Cortex-M0 core, and a variety of peripherals, providing a complete solution for BLE applications.

Applications

• Wearable devices: Smartwatches, fitness trackers, and medical sensors can utilize the CYBL10561-56LQXI for wireless communication with smartphones and other devices.
• Internet of Things (IoT) devices: Home automation sensors, industrial monitors, and asset tracking systems can leverage the BLE connectivity provided by this SoC.
• Beacons: Retail beacons and proximity marketing applications can use the CYBL10561-56LQXI for location-based services.
• Human Interface Devices (HIDs): Wireless keyboards, mice, and remote controls can benefit from the low-power and reliable connectivity of this BLE SoC.
• Healthcare applications: Continuous Glucose Monitoring (CGM) systems and other portable health monitoring devices.

Features

• Bluetooth 4.2 Low Energy (BLE) compliant: Supports the latest BLE standard for enhanced security and improved data throughput.
• 32-bit ARM Cortex-M0 core: Provides ample processing power for a wide range of applications.
• Integrated 2.4 GHz radio transceiver: Eliminates the need for external RF components, reducing board size and cost.
• Programmable analog and digital peripherals: Allows for flexible customization and integration with external sensors and actuators.
• Low power consumption: Maximizes battery life for portable and wearable devices.
• 56-pin QFN package: Provides a compact footprint for space-constrained applications.
• Integrated crystal oscillator: simplifies the design and reduces the bill of materials.

Benefits

• Reduced development time: The highly integrated nature of the CYBL10561-56LQXI simplifies hardware and software development.
• Lower system cost: Integrated peripherals and a compact package reduce the overall system cost.
• Improved battery life: Low power consumption extends battery life for portable applications.
• Enhanced security: BLE 4.2 support provides improved security features.
• Increased flexibility: Programmable peripherals allow for customization to meet specific application requirements.

Additional Details

The CYBL10561-56LQXI operates with a supply voltage of 1.9V to 3.6V. It features a wide operating temperature range, typically -40°C to +85°C. The integrated radio transceiver offers a programmable output power range, allowing for optimization of range and power consumption. Security features include AES-128 encryption and support for Bluetooth security features.
