AM29F010B-70JI

Part No AM29F010B-70JI
Manufacturer Cypress Semiconductor Corp
Catalog HOT - SALES and EOL Components (0 - A)
Description NOR Flash Parallel 5V 1M-bit 128K x 8 70ns 32-Pin PLCC / 1 Megabit (128 K x 8-bit) CMOS 5.0 Volt-only, Uniform Sector Flash Memory
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Manufacturer Cypress Semiconductor Corp
Supply Current 30(mA)
Address Bus 17(b)
Interface Type Parallel
Number of Words 128K
Operating Temperature (Min) -40C
Programmable Yes
Mounting Surface Mount
Access Time (Max) 70(ns)
Program/Erase Volt (Typ) 4.5 to 5.5(V)
Density 1048576(Bit)
Operating Temp Range -40C to 85C
Rad Hardened No
Word Size 8(b)
Operating Supply Voltage (Typ) 5(V)
Operating Supply Voltage (Min) 4.5(V)
Operating Supply Voltage (Max) 5.5(V)
Package Type PLCC
Operating Temperature (Max) 85C
Sync/Async Asynchronous
Operating Temperature Classification Industrial
Pin Count 32
Boot Type Not Required
Cell Type NOR
Win Source Part Number 083474-AM29F010B-70JI
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name Am29F010B
Introduction Date July 26, 1996
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian AM29F010B-70JI CAD Model

Description

AM29F010B-70JI Embedded Flash Memory

The AM29F010B-70JI is ideal for embedded system applications, supplying fast data retrieval times and reliable storage solutions. It is designed to operate under diverse conditions, ensuring consistent performance across various use cases.

  • Applications:
    • Digital Consumer Products
    • Aerospace Systems
    • Portable Devices
    • Robotics Control
  • Features and Benefits:
    • 70 ns Access Speed
    • 5V Single Power Supply
    • Advanced Sector Erase
    • Durability of Over 100,000 Cycles
  • Additional Details:This model's robust design and wide temperature range enhance its suitability for both consumer and industrial applications, providing reliable storage across different platforms.
