The TBL-1608-245-MA3 is a common mode choke manufactured by Cyntec. These chokes are specifically designed to suppress common-mode noise, a type of electromagnetic interference (EMI), in electronic circuits. By effectively filtering out common-mode noise, the TBL-1608-245-MA3 contributes to improved signal integrity, reduced EMI emissions, and enhanced overall system performance.

Applications

• USB Data Lines: Filtering common-mode noise on USB data lines to ensure reliable data transfer.
• Ethernet Interfaces: Reducing EMI in Ethernet connections for improved network performance.
• Power Lines: Suppressing noise on power lines to prevent interference with sensitive electronic equipment.
• Signal Lines: Filtering noise on signal lines to improve signal quality and reduce errors.
• Audio Circuits: Reducing noise in audio circuits for clearer sound reproduction.

Features

• High Common Mode Impedance: Provides a high impedance path for common-mode noise, effectively attenuating unwanted signals.
• Low Differential Mode Impedance: Presents a low impedance path for differential signals, allowing desired signals to pass through with minimal attenuation.
• Compact Size: Small footprint allows for easy integration into space-constrained applications.
• Surface Mount Technology (SMT): Designed for automated assembly using surface mount technology.
• RoHS Compliant: Compliant with Restriction of Hazardous Substances (RoHS) directive.

Benefits

• Improved Signal Integrity: Reduces common-mode noise, resulting in cleaner signals and more reliable data transmission.
• Reduced EMI Emissions: Minimizes electromagnetic interference, preventing unwanted radiation and improving system compatibility.
• Enhanced System Performance: Cleaner signals and reduced EMI contribute to improved system performance and reliability.
• Easy Integration: Small size and SMT design simplify integration into existing circuit designs.
• Environmental Compliance: RoHS compliance ensures that the product meets environmental regulations.

Technical Specifications

Specific details such as impedance at particular frequencies, DC resistance (DCR), rated current, and insulation resistance can be found in the manufacturer's datasheet for TBL-1608-245-MA3 from Cyntec.
