PS2565L-1 CEL
Same model may have multiple batches, images only for reference.

PS2565L-1

Part No PS2565L-1
Manufacturer CEL
Catalog Optoisolators - Transistor, Photovoltaic Output
Description HIGH ISOLATION VOLTAGE AC INPUT RESPONSE TYPE MULTI PHOTOCOUPLER SERIES | OPTOISOLATOR 5KV TRANS 4SMD
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer CEL
Packaging Tube
Status Obsolete
Voltage - Isolation 5000Vrms
Current Transfer Ratio (Minimum) 80% at 5mA
Current Transfer Ratio (Maximum) 400% at 5mA
Rise / Fall Time 3μs, 5μs
Input Type AC, DC
Output Type Transistor
Maximum Output Voltage 80V
Current - Output / Channel 50mA
Voltage - Forward (Vf) 1.17V
Current - DC Forward (If) (Maximum) 80mA
Vce Saturation (Maximum) 300mV
Temperature Range - Operating -55°C ~ 100°C
Mounting Style SMD
Manufacturer Package 4-SMD, Gull Wing
Supplier Device Package 4-SMD
Manufacturer Pack Quantity 100
MSL Level 1 (Unlimited)
Win Source Part Number 719958-PS2565L-1
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian PS2565L-1 CAD Model

Description

The CEL PS2565L-1 is an obsolete transistor type optocoupler.

  • Current Transfer Ratio: 80% @ 5mA, 400% @ 5mA maximum
  • Maximum Output Voltage: 80V
  • Current Output: 50mA
  • Vce Saturation: 300mV
  • Isolation Voltage: 5000Vrms
  • Package: 4-SMD
  • Popularity: Medium
