HCPL-0501-500E Broadcom Limited HCPL-0501-500E Real Image HCPL-0501-500E label picture 2 HCPL-0501-500E real image HCPL-0501-500E Real Image1 HCPL-0501-500E Real Image2 HCPL-0501-500E Real Image3 HCPL-0501-500E Real Image4 HCPL-0501-500E Real Image5 HCPL-0501-500E Real Image6
Same model may have multiple batches, images only for reference.
HCPL-0501-500E Broadcom Limited HCPL-0501-500E Real Image HCPL-0501-500E label picture 2 HCPL-0501-500E real image HCPL-0501-500E Real Image1 HCPL-0501-500E Real Image2 HCPL-0501-500E Real Image3 HCPL-0501-500E Real Image4 HCPL-0501-500E Real Image5 HCPL-0501-500E Real Image6
HCPL-0501-500E Broadcom Limited HCPL-0501-500E Real Image HCPL-0501-500E label picture 2 HCPL-0501-500E real image HCPL-0501-500E Real Image1 HCPL-0501-500E Real Image2 HCPL-0501-500E Real Image3 HCPL-0501-500E Real Image4 HCPL-0501-500E Real Image5 HCPL-0501-500E Real Image6
Same model may have multiple batches, images only for reference.

HCPL-0501-500E

Part No HCPL-0501-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Transistor, Photovoltaic Output
Description OPTOISO 3.75KV TRANS W/BASE 8SO
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Isolation Voltage 3750Vrms
Minimum DC Current Transfer Ratio 15% @ 16mA
Switching Turn-On and Turn-Off Time 200ns, 600ns
Input Type DC
Maximum Output Voltage 20V
Channel Output Current 8mA
Forward Voltage 1.5V
Continuous forward current- Max 25mA
Temperature Range - Operating -55°C to 100°C
Mounting SMD (SMT)
Case / Package 8-SO
Win Source Part Number 016828-HCPL-0501-500E
Family Name HCPL-0501
Introduction Date May 31, 2005
ECCN EAR99
Country of Origin Philippines
Estimated EOL Date 2023
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 1,500
Ultra Librarian 3D Model Ultra Librarian HCPL-0501-500E CAD Model

Description

The Broadcom Limited HCPL-0501-500E is a high-speed optocoupler designed for DC input applications.

  • Mounting Type: SMD (SMT)
  • Package: 8-SO
  • Maximum Output Voltage: 20V
  • Packaging: Reel - TR
  • Quantity per Package: 1,500
