AMMP-6120-TR1 Broadcom Limited AMMP-6120-TR1 Real Image AMMP-6120-TR1 label picture AMMP-6120-TR1 real image
Same model may have multiple batches, images only for reference.
AMMP-6120-TR1 Broadcom Limited AMMP-6120-TR1 Real Image AMMP-6120-TR1 label picture AMMP-6120-TR1 real image
AMMP-6120-TR1 Broadcom Limited AMMP-6120-TR1 Real Image AMMP-6120-TR1 label picture AMMP-6120-TR1 real image
Same model may have multiple batches, images only for reference.

AMMP-6120-TR1

Part No AMMP-6120-TR1
Manufacturer Broadcom Limited
Catalog RF Misc ICs and Modules
Description Active RF Multipliers x2 8GHz to 24GHz-OUT 8-Pin SMD T/R / 8-24 GHz x2 Frequency Multiplier 5x5mm Surface Mount Package | IC MMIC FREQ MULT 8-24GHZ 8-SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Tape and Reel
Status Obsolete
Function Frequency Multiplier
Frequency 4GHz ~ 12GHz
RF Type 802.16/WiMax; WLL; MMDS; DBS; VSAT
Secondary Attributes Active Frequency Multiplier
Manufacturer Package 8-QFN
Supplier Device Package 8-SMD (5x5)
Manufacturer Pack Quantity 100
MSL Level 2A (4 Weeks)
Win Source Part Number 709457-AMMP-6120-TR1
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name AMMP-6120
Introduction Date June 01, 2006
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian AMMP-6120-TR1 CAD Model

Description

The Broadcom Limited 709457-AMMP-6120-TR1 is a frequency multiplier that comes in an 8-SMD (5x5) package.

  • Manufacturer: Broadcom Limited
  • Frequency Range: 4GHz ~ 12GHz
  • Supply and Demand Status: Balanced
