ACML-7400-000E Real Image ACML-7400-000E Real Image
Same model may have multiple batches, images only for reference.
ACML-7400-000E Real Image ACML-7400-000E Real Image
ACML-7400-000E Real Image ACML-7400-000E Real Image
Same model may have multiple batches, images only for reference.

ACML-7400-000E

Part No ACML-7400-000E
Manufacturer Broadcom Limited
Catalog Digital Isolators
Description DGTL ISO 5.6KV GEN PURP 16SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube
Technology Magnetic Coupling
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Channel Type Unidirectional
Voltage - Isolation 5600Vrms
Common Mode Transient Immunity (Minimum) 25kV/μs
Data Rate 100MBd
Propagation Delay tpLH / tpHL (Maximum) 32ns, 32ns
Pulse Width Distortion (Maximum) 2ns
Rise / Fall Time (Typ) 3ns, 3ns
Operating Supply Voltage 3 V ~ 3.6 V, 4.5 V ~ 5.5 V
Operating Temperature Range -40°C ~ 125°C
Package 16-SOIC (0.295", 7.50mm Width)
Manufacturer Package 16-SOIC
Win Source Part Number 766910-ACML-7400-000E
Popularity Medium
Supply and Demand Status Balance
Quantity per package 45
Family Name ACML-7400
Introduction Date May 15, 2011
ECCN EAR99
Country of Origin Thailand
Halogen Free Not Compliant
Estimated EOL Date 2029
Ultra Librarian 3D Model Ultra Librarian ACML-7400-000E CAD Model

Description

The Broadcom Limited ACML-7400-000E is a 16-SOIC (0.295", 7.50mm Width) package technology with a magnetic coupling feature.

  • Package Type: 16-SOIC (0.295", 7.50mm Width)
  • Technology: Magnetic Coupling
  • Operating Temperature: -40°C ~ 125°C
  • Operating Supply Voltage: 3 V ~ 3.6 V, 4.5 V ~ 5.5 V
  • Data Rate: 100MBd
  • Channel Type: Unidirectional
  • Voltage Isolation: 5600Vrms
  • Inputs Side 1 / Side 2: 4 / 0
  • Isolated Power: No
  • Common Mode Transient Immunity (Minimum): 25kV/μs
  • Propagation Delay tpLH / tpHL (Maximum): 32ns, 32ns
  • Pulse Width Distortion (Maximum): 2ns
  • Supply and Demand: Balanced
  • Packaging: Tube
