SRU1038A-331Y Real Image
Same model may have multiple batches, images only for reference.

SRU1038A-331Y

Part No SRU1038A-331Y
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Description FIXED IND 330UH 550MA 1 OHM SMD / 330 µH Shielded Drum Core, Wirewound Inductor 550 mA 1Ohm Max Nonstandard
Datasheet
SRU1038A-331Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Manufacturer Bourns Inc.
Packaging Reel - TR
Type Drum Core, Wirewound
Material - Core Ferrite
Inductance 330 µH
Tolerance ±30%
Current Rating (Amps) 550 mA
Current - Saturation (Isat) 520mA
Shielding Shielded
DC Resistance (DCR) 1Ohm Max
Q @ Freq 20 @ 796kHz
Frequency - Self Resonant 3MHz
Ratings AEC-Q200
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting Surface Mount
Case / Package Nonstandard
Size / Dimension 0.394" L x 0.394" W (10.00mm x 10.00mm)
Height - Seated (Max) 0.161" (4.10mm)
Base Product Number SRU1038A
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Other Part Number SRU1038A-331YTR,SRU1038A-331YCT,SRU1038A-331Y-ND,SRU1038A-331YDKR
Standard Package 800
Win Source Part Number 1327995-SRU1038A-331Y
Ultra Librarian 3D Model Ultra Librarian SRU1038A-331Y CAD Model

Description

The Bourns Inc. SRU1038A-331Y inductor is a shielded drum core wirewound component.

  • Shielding: Shielded
  • Core Type: Drum Core Wirewound
  • Size: 0.394 inches in length and width
  • Height: 0.161 inches when seated
  • Inductance: 330 microhenries
  • Inductance Tolerance: ±30%
  • Rating: AEC-Q200
  • Core Material: Ferrite
  • Q: 20 @ 796kHz
  • Self-Resonant Frequency: 3MHz
  • DC Resistance: 1Ohm maximum
  • Operating Temperature Range: -40°C to 125°C
  • Mounting: Surface Mountable
  • Case/Package: Nonstandard
  • Current Rating: 550mA
  • REACH: Unaffected
  • ROHS3 Compliant: Yes
