Same model may have multiple batches, images only for reference.
SRP5030C-100M Real Image
Same model may have multiple batches, images only for reference.

SRP5030C-100M

Part No SRP5030C-100M
Manufacturer Bourns Inc.
Catalog Fixed Inductors
Datasheet
SRP5030C-100M Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes>Fixed Inductors
Mfr Bourns Inc.
Series SRP5030C
Package Tape & Reel
Material - Core Metal
Inductance 10 µH
Tolerance ±20%
Current Rating (Amps) 2.8 A
Current - Saturation (Isat) 2.8A
Shielding Shielded
DC Resistance (DCR) 122mOhm Max
Q @ Freq 20 @ 100kHz
Frequency - Self Resonant 15MHz
Temperature Range - Operating -40°C ~ 125°C
Inductance Frequency - Test 100 kHz
Mounting SMD (SMT)
Package / Case Nonstandard
Dimension 0.224" L x 0.205" W (5.70mm x 5.20mm)
Height - Seated (Max) 0.118" (3.00mm)
Other Names 118-SRP5030C-100MDKR,118-SRP5030C-100MTR,118-SRP5030C-100MCT
Standard Package 2,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1273879-SRP5030C-100M
Ultra Librarian 3D Model Ultra Librarian SRP5030C-100M CAD Model

Description

The SRP5030C-100M is a fixed inductor designed by Bourns Inc.

  • Shielded: Yes
  • Package: Tape & reel
  • Inductance: 10 µH
  • Height: 0.118" (3.00mm)
  • Standard Package: 2,000
  • Mounting: SMD (SMT)
  • Tolerance: ±20%
  • Material - Core: Metal
  • Q @ Freq: 20 @ 100kHz
  • Frequency - Self Resonant: 15MHz
  • Package / Case: Nonstandard
  • Temperature Range: -40°C to 125°C
  • Dimension: 0.224" L x 0.205" W (5.70mm x 5.20mm)
  • ECCN: EAR99
  • MSL Level: 1 (Unlimited)
  • REACH Status: REACH Unaffected
  • HTSUS: 8504.50.8000
  • Current Rating (amps): 2.8 A
  • Inductance Frequency - Test: 100 kHz
  • Current - Saturation (Isat): 2.8A
