The SDR0906 series drum core wirewound inductor is an unshielded type component with an inductance of 330μH and a tolerance of ±10%.

• Shielding: Unshielded
• Package: Tape and reel (TR), cut tape (CT)
• Package/Case: Non-standard
• Core Material: Ferrite
• Q @ Freq: 15 @ 796kHz
• Frequency-Self-Resonant: 5MHz
• DC Resistance (DCR): 1.27 Ohm Max
• Current Rating (Amps): 500 mA
• Temperature Range: -40°C to 125°C
• Dimension: 0.492" L x 0.413" W (12.50mm x 10.50mm)
• Height-Seated (Max): 0.248" (6.30mm)
• ECCN: EAR99
• HTSUS: 8504.50.4000
