A-DF 09 A/KG-T1 Assmann WSW Components – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

A-DF 09 A/KG-T1

Part No A-DF 09 A/KG-T1
Manufacturer Assmann WSW Components
Catalog D-Sub, D-Shaped Connectors - Assemblies
Description CONN D-SUB RCPT 9POS VERT SOLDER
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, InterconnectsD-Sub, D-Shaped ConnectorsD-Sub Connector Assemblies
Mfr Assmann WSW Components
Packaging Tray
Part Status Active
Connector Style D-Sub
Connector Type Receptacle, Female Sockets
Number of Positions 9
Number of Rows 2
Mounting Type Through Hole, Right Angle
Shell Size, Connector Layout 1 (DE, E)
Contact Type Signal
Flange Feature Board Side (4-40)
Termination Solder
Primary Material Metal
Shell Material, Finish Steel, Yellow Chromate Plated Cadmium
Contact Finish Gold
Material Flammability Rating UL94 V-0
Current Rating (Amps) 3A
Backset Spacing 0.406" (10.30mm)
Features Board Lock
Voltage Rating 125V
Color Black
Dielectric Material Polybutylene Terephthalate (PBT), Glass Filled
Contact Material Phosphor Bronze
Operating Temperature -55°C ~ 105°C
Ultra Librarian 3D Model Ultra Librarian A-DF 09 A/KG-T1 CAD Model
