AA05E-024L-150D

Get a Quote

Part No	AA05E-024L-150D
Manufacturer	Artesyn Embedded Technologies
Catalog	Power Supplies Board Mount DCDC Converters
Description	5 Watts \| DC DC CONVERTER +/-15V 5W
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Power Supplies - Board Mount
Manufacturer	Artesyn Embedded Technologies
Packaging	Bulk
Status	Obsolete
Type	Isolated Module
Number of Outputs	2
Voltage - Input (Minimum)	18V
Voltage - Input (Maximum)	36V
Voltage - Output 1	15V
Voltage - Output 2	-15V
Current - Output (Maximum)	160mA, 160mA
Power (W)	5W
Voltage - Isolation	1.5kV
Applications	ITE (Commercial)
Features	OVP, SCP
Temperature Range - Operating	-40°C ~ 85°C
Efficiency	85%
Mounting Style	Through Hole
Manufacturer Package	24-DIP Module (600 mil, 10 Leads)
Parts Dimension	1.25" L x 0.80" W x 0.40" H (32.2mm x 20.3mm x 10.2mm)
Manufacturer Pack Quantity	30
MSL Level	1 (Unlimited)
Win Source Part Number	1134859-AA05E-024L-150D
Manufacturer Homepage	www.astecinc.com/
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian AA05E-024L-150D CAD Model

Alternative Products

Description

The Artesyn Embedded Technologies Isolated Module is a high-quality power supply module designed for ITE (Commercial) applications.

Voltage Isolation: 1.5kV
Output 1 Voltage: 15V
Output 2 Voltage: -15V
Efficiency: 85%
Features: OVP and SCP
Package: 24-DIP module with 10 leads
Power: 5W
Input Voltage Range: 18V to 36V
Status: Obsolete
Supply and Demand Status: Limited
Output 1 Current: 160mA
Output 2 Current: 160mA
Dimensions: 1.25" L x 0.80" W x 0.40" H (32.2mm x 20.3mm x 10.2mm)
