Product Overview: ADG787BCBZ-REEL from Analog Devices Inc.

The ADG787BCBZ-REEL is a high-performance, low-voltage, dual 2:1 multiplexer/demultiplexer manufactured by Analog Devices Inc. This compact component comes in a surface-mount package and is provided on a reel, making it suitable for automated assembly processes and mass production. The device is designed for use in applications requiring efficient routing of digital or analog signals, including data acquisition systems, communication systems, and audio/video signal processing.

Key Features

• Low Voltage Operations: The ADG787 operates from a single 1.8 V to 5.5 V power supply, making it ideal for portable and battery-operated devices.
• Low On-Resistance: The on-resistance profile is very low, typically around 4 ohms, which minimizes signal attenuation and ensures high signal integrity.
• High Bandwidth: With a bandwidth greater than 200 MHz, the ADG787 can handle high-speed signals without significant distortion.
• Low Power Consumption: The device features ultra-low power dissipation, which extends battery life in portable applications.
• Bidirectional Signal Flow: The multiplexer/demultiplexer allows bidirectional data flow, adding to its versatility in various signal routing applications.
• ESD Protection: Enhanced electrostatic discharge (ESD) protection is built into the device, safeguarding it against damage from static electricity.

Applications

• Data Acquisition Systems
• Communication Systems
• Audio and Video Signal Routing
• Relay Replacement
• Portable and Battery-Powered Devices

Reliability and Quality

Analog Devices Inc. is known for its commitment to quality, and the ADG787BCBZ-REEL is no exception. It is designed to meet stringent industry standards, ensuring reliability and performance in even the most demanding applications. The device is also RoHS compliant, adhering to environmental regulations and promoting sustainability.

Conclusion

The ADG787BCBZ-REEL from Analog Devices Inc. is a versatile and reliable component for any design requiring efficient signal routing with minimal power consumption. Its low-voltage operation, high-speed capabilities, and robust protection features make it an excellent choice for designers looking to enhance the performance of their digital or analog systems.
