Products specifications

Categories Integrated Circuits
Manufacturer Altera
Status Active
Number of LABs/CLBs 645
Number of Logic Elements/Cells 10320
Total RAM Bits 423936
Number of I/O 182
Supply Voltage - Operating 1.15 V to 1.25 V
Mounting SMD (SMT)
Temperature Range - Operating -40°C to 100°C (TJ)
Case / Package 256-FBGA (17x17)
Win Source Part Number 084807-EP3C10F256I7N
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Communications & Networking
Family Name EP3C10
Introduction Date March 01, 2007
ECCN EAR99
Country of Origin Malaysia, Republic of Korea
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian EP3C10F256I7N CAD Model

Description

Overview

The EP3C10F256I7N is a sophisticated FPGA (Field-Programmable Gate Array) from the Cyclone III family. It serves as a robust solution for creating custom logic circuits and systems tailored to your specific needs.

Features and Benefits

  • Low power consumption for energy-efficient applications.
  • 256-pin TQFP package providing ample pin availability for complex designs.
  • Offers a maximum of 10,320 logic elements and 423,680 RAM bits for versatile functionality.
  • Wide temperature range support suitable for industrial applications.

Applications

  • Embedded systems for automotive applications.
  • Industrial automation and control systems.
  • Consumer electronics such as smart devices.
  • Prototyping and testing for new products development.
