EP2C20F484C8N Real Image EP2C20F484C8N real image EP2C20F484C8N real image3823
Same model may have multiple batches, images only for reference.
EP2C20F484C8N Real Image EP2C20F484C8N real image EP2C20F484C8N real image3823
EP2C20F484C8N Real Image EP2C20F484C8N real image EP2C20F484C8N real image3823
Same model may have multiple batches, images only for reference.

EP2C20F484C8N

Part No EP2C20F484C8N
Manufacturer Altera
Catalog Embedded - FPGAs (Field Programmable Gate Array)
Description IC FPGA 315 I/O 484FBGA / FPGA Cyclone® II Family 18752 Cells 402.58MHz 90nm Technology 1.2V 484-Pin FBGA
Datasheet
EP2C20F484C8N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Altera
Status Active
Number of LABs/CLBs 1172
Number of Logic Elements/Cells 18752
Total RAM Bits 239616
Number of I/O 315
Supply Voltage - Operating 1.15 V to 1.25 V
Mounting SMD (SMT)
Temperature Range - Operating 0°C to 85°C (TJ)
Case / Package 484-FBGA (23x23)
Win Source Part Number 084730-EP2C20F484C8N
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 60
Family Name EP2C20
Introduction Date June 01, 2004
ECCN 3A991
Country of Origin Indonesia, Philippines, Republic of Korea, Taiwan, Thailand
Halogen Free Compliant
Estimated EOL Date 2026
Ultra Librarian 3D Model Ultra Librarian EP2C20F484C8N CAD Model

Description

Product Overview

The EP2C20F484C8N is an FPGA device from the Cyclone II family, known for its high efficiency and cost-effective integration. Ideal for various applications, it provides the flexibility and performance needed for diverse electronic projects.

Features and Benefits

  • Capacity: 20,060 logic elements
  • Operating temperature range: Commercial (0°C to 85°C)
  • Low power consumption
  • Advanced I/O support for improved connectivity

Applications/Projects

  • Embedded processors
  • Digital signal processing
  • Data acquisition systems
