ASPI-0403S-5R6M-T Abracon LLC
Same model may have multiple batches, images only for reference.

ASPI-0403S-5R6M-T

Part No ASPI-0403S-5R6M-T
Manufacturer Abracon LLC
Catalog Fixed Inductors
Description FIXED IND 5.6UH 1.3A 62 MOHM SMD
Datasheet
ASPI-0403S-5R6M-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Inductors, Coils, Chokes - Fixed Inductors
Mfr Abracon LLC
Series ASPI-0403S
Package Tape & Reel (TR)
Product Status Active
Type Wirewound
Material - Core -
Inductance 5.6 µH
Tolerance ±20%
Current Rating (Amps) 1.3 A
Current - Saturation (Isat) -
Shielding Shielded
DC Resistance (DCR) 62mOhm Max
Q @ Freq -
Frequency - Self Resonant -
Ratings -
Temperature Range - Operating -40°C ~ 85°C
Inductance Frequency - Test 100 kHz
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package -
Size / Dimension 0.260" L x 0.175" W (6.60mm x 4.45mm)
Height - Seated (Max) 0.115" (2.92mm)
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1370640-ASPI-0403S-5R6M-T
Ultra Librarian 3D Model Ultra Librarian ASPI-0403S-5R6M-T CAD Model

Description

The ASPI-0403S-5R6M-T is a wirewound inductor manufactured by Abracon LLC.

  • Size: 0.260" L x 0.175" W (6.60mm x 4.45mm)
  • Height: 0.115" (2.92mm)
  • Inductance: 5.6µH
  • Tolerance: ±20%
  • Current Rating: 1.3A
  • DC Resistance: 62mOhm Max
  • Mounting Type: Surface Mount
  • Shielded: Yes
  • Temperature Range: -40°C to 85°C
  • Series: ASPI-0403S
  • Package: Tape and Reel
