Same model may have multiple batches, images only for reference.

TPC8125,LQ(S

Name: TPC8125,LQ(S
Brand: Toshiba Semiconductor and Storage
SKU: 735388
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

Part No	TPC8125,LQ(S
Manufacturer	Toshiba Semiconductor and Storage
Catalog	FETs - Single
Description	MOSFET P-CH 30V 10A 8SOP
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Toshiba Semiconductor and Storage
Packaging	Tape and Reel
Transistor Polarity	P-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	30V
Id - Continuous Drain Current	10A
Drive Voltage (Max Rds On, Min Rds On)	4.5V, 10V
Rds On (Maximum) at Id, Vgs	13mOhm at 5A, 10V
Gate Source Voltage(th) (Maximum) at Id	2V at 500μA
Gate Charge (Qg) (Maximum) at Vgs	64nC at 10V
Gate Source Voltage (Maximum)	+20V, -25V
Input Capacitance (Ciss) (Maximum) at Vds	2580pF at 10V
Power Dissipation (Maximum)	1W
Temperature Range - Operating	150°C
Mounting Style	SMD
Supplier Device Package	8-SOP
Manufacturer Package	8-SOIC
Manufacturer Pack Quantity	2,500
MSL Level	1 (Unlimited)
Win Source Part Number	735388-TPC8125,LQ(S
Popularity	Low
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian TPC8125,LQ(S CAD Model

Alternative Products

Description

The Toshiba Semiconductor and Storage MOSFET is a P-channel FET transistor designed for use in discrete semiconductor products.

Drain-Source Breakdown Voltage: 30V
Continuous Drain Current: 10A
Rds on (Max): 13mOhm @ 5A and 10V
Power Dissipation: up to 1W
Package: 8-SOIC
Mounting: SMD technology
Gate-Source Voltage Threshold: 2V @ 500μA
Maximum Gate-Source Voltage: +20V, -25V
Input Capacitance: 2580pF @ 10V
Gate Charge: 64nC @ 10V
Operating Temperature: up to 150°C
