SN74ACT14DR

Name: SN74ACT14DR
Brand: Texas Instruments
SKU: 331387
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SN74ACT14DR
Manufacturer	Texas Instruments
Catalog	Logic - Gates and Inverters
Description	IC HEX SCHMITT-TRIG INV 14-SOIC / Inverter Schmitt Trigger 6-Element CMOS 14-Pin SOIC T/R
Datasheet	SN74ACT14DR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Features	Schmitt Trigger
Supply Voltage - Operating	4.5 V to 5.5 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	24mA, 24mA
Logic Level - Low	0.5 V to 0.6 V
Logic Level - High	1.9 V to 2.1 V
Max Propagation Delay @ V, Max CL	11.5ns @ 5V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	14-SOIC
Dimension	14-SOIC (0.154", 3.90mm Width)
Win Source Part Number	029696-SN74ACT14DR
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Family Name	SN74ACT14
Introduction Date	August 01, 2003
ECCN	EAR99
Country of Origin	Malaysia, Mexico
Halogen Free	Compliant
Estimated EOL Date	2031
Ultra Librarian 3D Model	Ultra Librarian SN74ACT14DR CAD Model

Alternative Products

Description

The SN74ACT14DR from Texas Instruments is a high-performance, advanced CMOS (Complementary Metal-Oxide-Semiconductor) device that is specifically designed to offer superior functionality and performance in a variety of applications.

Device Type: Hex Schmitt-Trigger Inverter
Supply Voltage: 4.5V to 5.5V
Feature: Hysteresis
Package: Small-outline integrated circuit (SOIC)
RoHS Compliant: Yes
Operating Temperature Range: -40°C to 85°C
Output Drive: ±24mA @ the outputs
Propagation Delay Time: 8ns @ 5V
