INA143U Real Image INA143U Real Image
Same model may have multiple batches, images only for reference.
INA143U Real Image INA143U Real Image
INA143U Real Image INA143U Real Image
Same model may have multiple batches, images only for reference.

INA143U

Part No INA143U
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP DIFF 150KHZ 8SOIC
Datasheet
INA143U Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Amplifier Type Differential
Number of Circuits 1
Slew Rate 5 V/μs
-3db Bandwidth 150kHz
Voltage - Input Offset 100μV
Operating Supply Current 950μA
Channel Output Current 32mA
Supply Voltage - Operating 4.5 V to 36 V, ±2.25 V to 18 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 001798-INA143U
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian INA143U CAD Model

Description

The INA143U from Texas Instruments is a high-performance, precision instrumentation amplifier with a unique combination of features that make it exceptionally versatile and adaptable to a wide range of applications.

  • Gain Range: 1 to 1000
  • Input Bias Current: Extremely low
  • Common-Mode Rejection Ratio (CMRR): up to 120 dB
  • Power Supply: from +2.7V to +36V, or from dual supplies of ±1.35V to ±18V
  • Temperature Range: -40°C to +85°C
