The ESDA6V1SC6 from STMicroelectronics is a state-of-the-art Transil™ diode designed to protect sensitive electronic equipment from electrostatic discharges (ESD). This robust ESD suppressor is essential for modern electronics where high-speed data lines and sensitive components require advanced protection against the sudden surges caused by ESD events.

Key Features

• Peak Pulse Power: The ESDA6V1SC6 can withstand ESD strikes as per the IEC 61000-4-2 standard, providing a peak pulse power dissipation of up to 200 W (8/20 µs).
• Low Clamping Voltage: It offers an extremely low clamping voltage, ensuring that even the most sensitive circuits are well protected.
• Low Leakage Current: With its minimal leakage current, it ensures that the device does not significantly affect the normal operation of the protected circuit over time.
• Multi-Line Protection: This device is capable of protecting up to 5 data lines, making it an efficient solution for compact electronic assemblies.
• Small Package: Housed in an SOT-23-6L package, it is suitable for high-density circuit designs where space is at a premium.

Applications

The ESDA6V1SC6 is ideal for a wide range of applications where ESD protection is critical. These include:

• USB interfaces, including USB 2.0 and 3.0
• HDMI, Ethernet, and other high-speed data interfaces
• Mobile phones and other portable devices
• Microcontroller input/output protection
• Memory and SIM card interfaces

Reliability and Quality

As with all STMicroelectronics products, the ESDA6V1SC6 is manufactured to the highest quality standards. The device's reliability is ensured by rigorous testing procedures, and it is compliant with the RoHS directive, making it suitable for use in environmentally-sensitive applications.

Protect your electronic investments with the ESDA6V1SC6, a compact, high-performance solution from STMicroelectronics, a leader in integrated ESD protection solutions.
